Kasutusjuhend Indesit BDE 96436 EWSV EE Kuivatiga pesumasin

Kasutusjuhend

GB

User Manual

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button and indicator light

3. TEMPERATURE button

4. DISPLAY

5. OPTIONS button

6. DRYING ONLY button

7. DRYING button

8. DELAYED START button

9. SPIN button

10. WASH CYCLE SELECTOR KNOB

11. PUSH & GO button

WASH CYCLE TABLE

Prior to using the appliance, carefully read the Safety and installation instructions.

Prior to using the appliance, the bolts used for transport must be removed. For detailed

instructions on the removal procedure, consult the safety and installation instructions.

PRODUCT DESCRIPTION

1.

3.

2.

5.

4.

7.

6.

8.

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

1

10

2 3

5

89

11

4

6

7

For all testing institutes:

2) Long cotton cycle: set programme 6 at temperature 40°C.

3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.

* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

**** The display will show the suggested spin speed as default value.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected. The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation

2019/2014. The most ecient programme in terms of energy and water consumption for

washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in

the table.

5) Eco 40-60 (Wash & Drying)-

Test

wash and

drying cycle in compliance with EU

Ecodesign regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash

programme and set option level to

“ ”.

The most ecient programme in terms of energy

and water consumption for washing and drying normally soiled cotton laundry. At the end of

cycle the garments can be immediately stored to the cupboard.

DETERGENT DISPENSER DRAWER

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage.

If powder detergent is used, insert the partition

into slot B.

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the “max”

level indicated on the central pin.

! The detergent drawer is suitable only for Liquid

and Powder detergent. No Capsule detergent allowed.

The Capsule detergent have to be placed into the drum before the load.

Make sure to use the correct Capsule detergent dosage amount

recommended by Manufacturer.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever C and pull the drawer outwards.

C

Maximum load 9 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(***)

Energy

consumption

kWh

Total water lt

Laundry

temperature °C

Wash cycle

Temperature

Max.

spin speed

(rpm)

Max.

load for

washing

(kg)

Duration

(h : m)

Drying

Max.

load for

drying

(kg)

Wash

Fabric

softener

Powder

Liquid

Capsule

(4)

Setting Range 2 3

1

Mixed

30 °C 30 °C 1200 3.5

** – –

 

–



– – – – –

2

Shirt

40 °C

- 40 °C

600 2

** – –

 

–

 

– – – –

3 PODS

30 °C 30 °C 1000 4.5

** – – –



– –



– – – –

4 Wool 40 °C

- 40 °C

800 2 **



2

 

–



–

– – – –

5 20°C 20 °C

- 20 °C

1400 9 1:50



6

 

–



–

49 0.160 90 22

6 Cotton (2) 40 °C

- 60 °C

1400 9 3:55



6

   



49 1.400 105 45

7 Synthetics (3) 40 °C

- 60 °C

1200 4 2:55



4

   



35 0.800 55 43

8 Mixed 40 °C

- 40 °C

1000 9 **



6

 

–





– – – –

9

Eco 40-60 (1)

(Wash)

40 °C 40°C

1351 9 3:48



6

   



53 0.730 59 35

1351 4.5 2:54

    



53 0.515 57 32

1351 2.5 2:15

    



53 0.280 38 23

10 White 60 °C

- 90 °C

1400 9 2:45



6

   



49 0.900 90 55

11 Rapid 15min 20 °C

- 20 °C

1200 (****) 1.5

** – –

 

–



– – – – –

12

Rapid 45min Full Load

40°C - 40°C 1200 9 ** – –

 

–



–

– – – –

13 Wash&Dry 45min 30 °C 30 °C 1400 1 **



1

 

–



– – – – –

14 Delicates 30°C 30 °C

- 30 °C

600 (****) 1 **



1

 

–



– – – – –

Rinse + Spin – – 1400 9 **



6 –



– – – – – – –

Spin + Drain * – – 1400 9 **



6 – – – – – – – – –

 Required dosage  Optional dosage - 4) Minimum 30°C recommended for usage of Capsule detergent.

9

Eco 40-60 (5)

(Wash&Drying)

40 °C 40 °C

1351 6 9:20



6

   

– 0 3.800 75 33

1351 3 5:10



3

   

– 0 1.980 47 32

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register
