GB

9

Operating Instructions

WOOD’S FOR CLEAN AND HEALTHY

INDOOR AIR

The brand Wood’s was born with the

Wood’s family over 65 years ago in the

Canadian city of Guelph, Ontario. This

is where Wood’s began developing and

manufactoring dehumidiers in 1950. Since

then Wood’s has helped several hundred

thousand households to prevent damages

from mould damp, and to breathe

cleaner air. Our portable air conditioners

are suitable for use in most climates,

where capacity is good even at dierent

temperatures and humidity levels. They

are used with good results in premises that

become hot such as livingrooms, oces

or bedrooms. The amount of hot air that

the air conditioner removes depends

on the temperature, humidity level and

placement. External weather conditions

may also aect the performance of the air

conditioner.

Wood’s air conditioners are safe in

operation and intended for continuous use

over many years.

HOW DOES THE AIR CONDITIONING

UNIT WORK?

Low pressure gives cold air

The main element of the air conditioner

is a coolant, which under low pressure is

converted to gas. The process “creates

cold”, which is transmitted inward, while

keeping the warm air out.

A liquid coolant is passed through an

expansion valve and into a pipe where the

pressure is low.

The coolant evaporates and turns into a

gas. The process absorbs heat from the

surroundings and the pipe is cooled.

A fan blows the cold air into the room.

The gas is passed through a compressor,

which increases the pressure and converts

the gas into liquid.

In this process, heat is released, which

is led to pipes on the opposite side and

blown out by a fan.

A thermostat shuts o the unit when the

indoor air is cold enough.

1. SECURITY WARNINGS

Flammable material. This

appliance contains R290/

Propane a ammable refrigerant.

Refer to this manual for

safety information.

Read technical manual

Read operators manual.

SAFETY INFORMATION

Before the installation and use

of the appliance, carefully read

the supplied instructions. The

manufacturer is not responsible

if an incorrect installation and

use causes injuries and damages.

Always keep the instructions with

the appliance for future reference.

Children and vulnerable people

safety

WARNING

Risk of injury or permanent

disability.

This appliance can be used by

children aged 8 years and above

and persons with reduced physical,

sensory or mental capabilities or

lack of experience and knowledge

if they have been given supervision

or instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

Do not let children play with the

appliance.

Children of less than 3 years should

be kept away unless continuously

supervised.

Keep all packaging away from

children.

Cleaning and user maintenance

shall not be made by children

without supervision.

General Safety

This appliance is intended to be

used in household and similar

applications such as: Family room,

living room, sta kitchen areas in

shops, oces and other working

environments. The rating plate is

located at the side or back of the

Air Conditioner.

Keep ventilation openings clear of

obstruction.

Do not use mechanical devices

or other means to accelerate the

defrosting process, other than

those recommended by the

manufacturer.

The appliance shall not be stored

in a room with operating ignition

sources (for example: open ames,

an operating gas appliance or an

operation electric heater. Do not

pierce or burn.

Be aware that refrigerants may

not contain an odour. Do not use

water spray and steam to clean the

appliance. Clean the appliance with

a moist soft cloth. Only use neutral

detergents. Do not use abrasive

products, abrasive cleaning pads,

solvents or metal objects.

If the supply cord is damaged,

it must be replaced by the
