Kasutusjuhend Scarlett SC-057 Kütteseade

Kasutusjuhend

IM013

www.scarlett.ru SC-057

3

GB INSTRUCTION MANUAL

IMPORTANT SAFEGUARDS

• Please read all the instruction manual before use and save it for future references.

• Before first switching on check that the voltage indicated on the rating label corresponds with the mains voltage in your

home.

• For home use only. Do not use for industrial purposes. Use the appliance only for its intended use.

• Do not use outdoors or in damp area.

• To prevent risk of electric shock and fire, do not immerse the appliance in water or any other liquids. If it has happened

DO NOT TOUCH the appliance, unplug it immediately and check in a service center.

• Do not use the appliance in immediate proximity to а bath, а shower or а swimming pool.

• Never pull the cord while disconnecting from the power outlet; instead, grasp the plug only and pull to disconnect.

• Do not allow the cord to touch sharp edges and hot surfaces.

• Always unplug the appliance from the power supply when not in use.

• If the power cord is damaged it should be replaced by the manufacturer or authorized servicing center or qualified

professional for safety reasons.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning

use of the appliances by a person responsible for their safety.

• Children should be supervised and should not be permitted to play with the oven.

• Do not leave appliance unattended while operating.

• The appliance must be used only in the upright position.

• Unit surface temperature of the appliance is high, thus do not touch it, except the handle.

CAUTION:

• To avoid a circuit overload, do not operate another high wattage appliance on the same circuit.

• Do not cover the appliance when in use.

• The heater is filled with a certain quantity of special oil. Any maintenance that requires opening of the oil tank may be

performed only by the manufacturer or its authorized service center that should repair the appliance in case of oil

leakage.

• It is necessary to follow the instructions concerning used oil utilization.

• Do not attempt to repair, adjust or replace parts in the appliance. Repair the malfunctioning appliance in the nearest

service center.

• If the product has been exposed to temperatures below 0ºC for some time it should be kept at room temperature for at

least 2 hours before turning it on.

• The manufacturer reserves the right to introduce minor changes into the product design without prior notice, unless

such changes influence significantly the product safety, performance, and functions.

WHEELS MOUNTING

• First turn the unit upside-down.

• Install multidirectional rolling wheels to each end between the first and the second groups of the heating flanges and

secure it with screws.

• Place heater normally and make sure that it is inconvertible.

USING THE APPLIANCE

• Set the power regulators in "0" position and set the temperature regulator in vertical position.

• Connect the appliance to the mains.

POWER SELECTOR

• You can adjust oil heater current power using power regulator:

– “0” – Off;

– “I“ – Minimum power;

– “II” – Medium power;

– “I“ + “II” simultaneously – Maximum power.

THERMOSTAT

• Rotate the temperature regulator clockwise up to the stop to set maximum temperature.

• When the temperature rises to satisfying level, slowly turn the thermostat counterclockwise until the indicator lights is

out, and the room temperature thus can keep constant.

• If you want to change the room temperature, you can make another regulation: turn the thermostat clockwise to arise

the temperature and counterclockwise to lower it.

• When the temperature is below than thermostat set value, heating element will switch on and corresponding indicator

will light (or both indicators if maximum power was set).

HUMIDIFIER

• Open the humidifier with the tab at the top.

• Fill the water tank of detachable humidifier with water and establish it on the top of appliance.

• Depending on heating temperature, the maximal relative humidity will be near 50-60%.

NOTES:

• The room must be properly sealed, if not, using of oil heater will not make good result because of heat

leakage.

• After use, turn the power selector to the “0” position, then turn the thermostat to the “0” position and unplug from

power supply.
